Online Vibrating Tube Liquid Density Meter

With real-time density measurement accuracy at 0.0005g/cm³ (up to 0.0002g/cm³), KDM online vibrating tube liquid density meter is designed to offer solutions to oils stratification and tank change.

PRODUCTS
SPECIFICATIONS
FEATURES
DOCUMENTS & DRAWINGS

KDM

KDM Online Vibrating Tube Liquid Density Meters

With real-time density measurement accuracy at 0.0002g/cm³ (0.0005g/cm³ and 0.001g/cm³), KDM online vibrating tube liquid density meter is designed to offer solutions to oils stratification and tank change.

DETAILS
KDM-C

KDM-C Online Vibrating Tube Liquid Density Meters

With real-time density measurement accuracy at 0.0002g/cm³ (up to 0.0001g/cm³), KDM online vibrating tube liquid density meter is designed to offer solutions to oils stratification and tank change.

DETAILS
KDM-S

KDM-S Online Vibrating Tube Liquid Density Meters

With real-time density measurement accuracy at 0.0005g/cm³ (up to 0.0003g/cm³), KDM-S density meter adopts straight tube design, low pressure loss, high measurement accuracy, easy cleaning, and wide applicable media. It is particularly suitable for density measurement under high cleanliness or complex working conditions.

DETAILS
KDM-HP

Ultra-high pressure cement slurry liquid density meter- KDM-HP

Ultra-high pressure cement slurry liquid density meter is used in oil drilling, cementing platform and other high pressure working conditions, with real-time density measurement accuracy at 0.02g/cm³. The joint is 2-inch 1502 hammer union with a maximum pressure resistance of 15000Psi

DETAILS

1PAGES4

SPECIFICATIONS

Temperature	Measurement Range		-40℃~+ 204℃
	Accuracy		±0.1℃
	Repeatabillity		0.05℃
Electrical parameters	Power Supply		24VDC、220VAC
Electrical parameters	Output Slgnal		RS-485、4-20mA、pulse
Environmental parameters	Operation Temperature		-40℃~ +60t℃
Explosion-proof	Explosion-proof Grade	Sensor	Exib IIC T1~T6 Gb
Explosion-proof	Explosion-proof Grade	Transmitter	Ex d[ib]IIC T6 Gb
Protection	Protection Grade	Sensor	IP66/IP67
Protection	Protection Grade	Transmitter	IP66/IP67
Standard	JJG 370-2019 online vibration tube liquid density meter calibration procedures

FEATURES

· Get real-time measurement accuracy at 0.0005g/cm3 (up to 0.0001g/cm³)

· Offer best solutions to oils stratification and tank change

· Implement the widest process-measurement range -40°C to +240°C

· Improve V20 delivery accuracy

· Improve real time density measurement accuracy

· Flexible management of oil depot loss

· No need for sampling, ensure safety and avoid pollution

· Reduce manual sampling workload

· Dynamic Measurement, Offer Solutions to Oils Stratification and Tank Changing
